WWII Navy Transmitters & Transceivers

waves-bug.jpg (104666 bytes) Go to http://www.qrz.com/db/KD6TKX to see Andy's really great WW2 Navy Radio Shack



Portable and Mobile transmitter-receiver page (MAB, MAR, MBF, TBX, TBY, etc.)

WW2 Era Shipboard and Shore Station LF/MF/HF Transmitters
(Go here for WW2 Era VHF/UHF Transmitters)

TAB
TAB Spec Sheets

 100-55 KC, 2kw CW -- --

TAJ-19
TAJ Spec Sheets


TAJ19-05.JPG (12994 bytes) TAJ19-06.JPG (18751 bytes) TAJ19-07.JPG (16705 bytes) TAJ19-09.jpg (24965 bytes)

TBA
TBA Spec Sheets

4-26mc, 1000w

TBA-6 aboard USS Texas

TBC

TBC Spec Sheets

40-50KW, CW, 4-26MC

Water Cooled



Photos thanks to Jeff WB6ZBX
TBC-A.jpg (714145 bytes) 		TBC-B.jpg (724569 bytes) TBC-C.jpg (743907 bytes) TBC-D.jpg (811192 bytes)

TBD

 article in Electric Radio magazine Nov 2002 p32 - -

TBK
TBK Spec Sheets

Info on all TBK Models

TBK-18

TBK-18
Andy's restored TBK-18 plus TBM Modulator

CRV-50194 Modulator (Specs)




tbk-mod-1709-03.jpg (276827 bytes) tbk-mod-1709-06.jpg (365714 bytes) tbk-mod-1709-05.jpg (228770 bytes) tbk-mod-1709-04.jpg (248403 bytes)

TBL
TBL Spec Sheets

 article in Electric Radio magazine Oct 2001 p38

TBL-8 Video - restoration

 - -

TBL Speech Input Equipment CME-50064
CQE-50064A


50064A spec Sheet


Receiver Attenuator CQE-29017
- part of TBL Speech Input Equipment



 --

TBM-7 - Video of operation aboard USS Massachusetts

TBM Spec Sheets

 - -
TBM-7 aboard USS Texas

TBM telephone & remote control unit (CAY-23304-A)



TCB
TCB Spec Sheets

--

 -article in Electric Radio magazine Mar 1996 p32 -

TCK-4

TCK Spec Sheets

2-18.1mc
400w CW, 100w AM

TCK Restoration Video





TCK motor-generator set


TCK-4, -6 Transmission Line Coupling Unit - CG-50139


TCM, TCN, TCU

TCM is HF only (2-18mc)
TCU is MF only (300-2000kc)
TCN is HF + MF


TCO-2 (CRM-43206)
TCO Spec Sheets


tco2-110507-06.jpg (338525 bytes) tco2-110507-07.jpg (358439 bytes) tco2-110507-08.jpg (315448 bytes) tco2-110507-09.jpg (275961 bytes)
tco2-110507-10.jpg (311782 bytes) tco2-110507-11.jpg (308780 bytes) tco2-110507-12.jpg (206487 bytes) manuf Radiomarine

TCP-2 (CRM-43010-A)
TCP Spec Sheets

TCP-2 Manual



TCP-3


TCP-3 remote control CRM-23230


TCP-3 handset CRM-51026

 -- -- --

TCR  (CRM-52207)
TCR Spec Sheets


2-3mc 125w remotely-controlled radiophone xmtr

Radiomarine Corp


CRM-52207 Transmitter
CRM-23242 Control Unit
CRM-51027 Hand Telephone Assembly







TCS - Photo and Info Page


 --

TCU - see TCM above

TCZ, TCZ-1, TCZ-2



Adaptation of ATC (AN/ART-13) transmitter

  TCZ Spec Sheets




tcz1-1411-08.JPG (383545 bytes) tcz1-1411-09.JPG (355035 bytes) tcz1-1411-01.JPG (461460 bytes) tcz1-1411-02.JPG (455175 bytes)
tcz1-1411-03.JPG (387406 bytes) tcz1-1411-04.JPG (431077 bytes) tcz1-1411-05.JPG (299559 bytes) tcz1-1411-06.JPG (283484 bytes)
TCZ - 1955 USN restoration - photos thanks to Paul N6FEG








TDA
Radiomarine ET-8010-C


200w A1, A2

2 ea. 807, 2 ea. 211

Spec sheet

Info

 ==

TDB, TDB-2
AN/SRT-4A
Radiomarine  ET-8019-A

2000-22140 kc

2 ea. 807, 2 ea. 813

200w A1, A2



 TDB


 TDB-2
tdb-srt4a_9419.jpg (2304779 bytes) tdb-srt4a_9425.jpg (2636361 bytes) tdb-srt4a_9414.jpg (1246685 bytes) tdb-srt4a_9415.jpg (3127284 bytes)







tdb-srt4a_9426.jpg (3632249 bytes) tdb-srt4a_9427.jpg (2322624 bytes) tdb-srt4a_9428.jpg (3217220 bytes) tdb-srt4a_9429.jpg (3501324 bytes)



TDD (CCI-52258)
TDD Spec Sheets



MF transmitter for airport traffic control
15 w AM, 200-550kc



TDF (CRM-52261)

125 watts CW/AM
2.0-9.4 MC

Manuf by Radiomarine

Partial Manual (thanks to Elden)


TDO
TDO Spec Sheets

NOS TDO movie



400w CW, 250w AM, 2-18 mc
two 813's modulated by two 805's



TEB (CYV-52353)
TEB Spec Sheets


 Shore Station
4-21 MC, 15 kw, CW/FSK

Navy version of Press Wireless PW-15
 - photo of TEB at KTK

Radio Transmitting Equipment TEB is used for general purpose, high-power, h-f, radiotelegraph, or frequency-shift operation in shore-to-ship, and point-to-point communication. Vacuum-tube keying speeds up to 400 wpm are possible, and provision is made for the connection of an external frequency shift keyer.
Six preset crystal-controlled channels ore available, and provision is made for connection of an external master oscillator.
An automatic control circuit will shut down the entire equipment, except blowers and oscillator oven, if the transmitter is not keyed for a predetermined period (adjustable from two to 30 minutes).
This equipment is designed to work into a balanced two-wire transmission line of 550 to 650 ohm impedance and zero reactance.

TEC
TEC Spec Sheets


Shore Station
4-21 MC, 40 kw, CW/FSK

Navy version of Press Wireless PW-40

NAVSHIPS 900,212


TED UHF Transmitter
TED Spec Sheets

TED-6

 UHF 225-400 mc AM
15 watts output



 NAVSHIPS 91357

Circuit Description - 4.5 MB pdf


TEF

TEF Spec Sheets


Western Electric D-15600

Manual



TEG (ship/shore)
TEG Development Info

Many more Photos


TEG-1 (shore station)










evidently did not go into production manuf RCA

TEJ or X-TEJ Series
Development Info

became AN/URT-2, URT-3, URT-4

AN/URT-2, URT-3, URT-4 Info - -

Philips SVC100L/110 - about 300 of them made in Australia for the US Navy - 1944
Philips_Tx_SVC100L-110_USN_info-01.JPG (1204677 bytes) Philips_Tx_SVC100L-110_USN_info-02.JPG (1129741 bytes) Philips_Tx_SVC100L-110_USN_plate.JPG (2436982 bytes)

thanks to Kevin VK6KQ for this info and photos of this transmitter he found
